ZXP3 QuikCard ID

Ribbons & Laminates

  • Overview
  • Specs
  • Quote
For consistent high-quality output from your Zebra card printer, use Zebra's TrueColours® print ribbons. TrueColours ribbons deliver vibrant color photos and "true-to-life" flesh tones, as well as sharp monochrome bar codes and text.

Prolong card life with Zebra's patented overlay ("O panel") in the ribbons, which protects your card against dye migration and abrasions. TrueColours ribbons are also designed to help extend the life of your Zebra card printer with a unique silicone-based coating that minimizes printhead debris. Ribbons without this coating allow particulate build-up on the printhead, which may decrease the life of this critical printer part.

TrueColours Monochrome Resin ribbons

Zebra TrueColours® Monochrome Resin Ribbons use "thermal transfer" printing technology, a process by which a heated printhead is used to transfer a digitized image from the ribbon to the surface of the card. Monochrome ribbons can be used on all Zebra card printers. They are available in a variety of colors including black, red, green, blue, gold, silver, white and scratch-off gray.

TrueColours multi panel ribbons

Zebra TrueColours® Multi-panel ribbons are developed with the newest technology in dyes available. Multi-panel ribbons use dye-sublimation, which means the color dye is vaporized into a gaseous state and then diffused onto the cards at the printhead station.

Security Featured Ribbons

Prevent unauthorized use of your card printer and supplies with print ribbons that have factory programmed customer security codes. The printer will authenticate the ribbon security code before printing, helping keep your ID issuance process secure.

Download ZXP Series 3 Brochure
Zebra ZXP Series 3 Duplex Specifications
Printing Capability: Single or Dual sided printing
Color Capability: Colour and monochrom printing
Printing Speeds (sec/card): 4.8 seconds (monochrome (K) single-sided card)
20 seconds (full-color (YMCKO) single-sided card)
26 seconds (full-color (YMCKOK) dual-sided card)
Input Hopper Capacity: 100
Output Hopper Capacity: 45
15-card reject hopper
Card Sizes Accepted: CR80 - standard credit card size
Card Thickness Accepted: 30 mil
Interface: USB 2.0 (optional Ethernet and/or Parallel)
Software Drivers: Microsoft® Windows® Server 2003 & 2008, XP, Vista (32- & 64-bit), & Windows 7 (32- & 64-bit)
Warranty: 2 years on printer and printhead
Weight & Dimensions: 2 years on printer and printhead
Printer Includes: USB cable
Power cord
Microsoft Windows drivers
Printer Options: Encoding -
» Magnetic stripe - 3 track HiCo/LoCo
» Smart card contact station (ISO 7816)
» Combined MIFARE ISO 14443 (13.56 MHZ) & ISO 7816 contact encoder
Built-in 10/100 Ethernet connectivity
Lockable enclosure/card feeder & obscured output hopper
Extended warranties through ID Wholesaler, including options to add printer loaner coverage to standard warranty
CardStudio ID Card Software Specifications
Printing Capability: Full-color one-sided or two-sided (duplex) capabilities
Database: Import Microsoft Excel & CSV records
Encoding: 1-D (linear) and 2D barcodes
Magnetic stripe:
Card Management Import images
Integrated photo capture
Add up to 8 data fields
Options: Upgrade to Professional edition
System Requirements: Pentium microprocesor 512MB RAM (1GB recommended)
250MB with partial clipart or 400MB with full clipart installed of free disk space
CD ROM 8x or greater drive
Printer support via CardStuido Direct-to-Printer (D2P) techology or Zebra certified
Microsoft Windows drivers
MS Window XP, Vista, or Windows 7
